Thermaltake AX700 TG Super Tower Chassis Black (CA-11B-00F1WN-00)

Key Features

Optimize Your Workstation

The AX700 TG Super Tower Chassis is a high-performance workstation super tower designed for content creators, small enterprises, and gamers, offering exceptional performance, storage, and cooling. It supports an XL-ATX motherboard, up to five 2-slot graphics cards, and eighteen 3.5” hard drives, making it ideal for demanding tasks like video editing and AI computing. With advanced thermal management, including space for up to eighteen 120mm fans and large radiators, the AX700 TG Super Tower Chassis ensures optimal airflow and hardware longevity.

Versatile Expandability

The AX700 TG Super Tower Chassis and AX100 pedestal offer multiple stacking options, either on top or bottom, or both top and bottom, creating an expandable system for enthusiasts. This setup allows for enhanced liquid cooling, storage, or dual system configurations, taking the expandability to the next level.

Premium Cooling Solutions

Supports up to eighteen 120mm/140mm fans and a 560mm DIY or 420mm AIO radiator on top for optimal thermal performance.

GPU Holder

The AX700 series chassis features a built-in graphics card holder for added support, preventing sagging with multiple GPUs.

One Tempered Glass and One Perforated Side Panel

The tempered glass left side panel provides the better visibility and the perforated right side panel ensures better airflow, and the hinged design gives the easy access.

Perfect Dust Protection

The AX700 TG Super Tower Chassis features dust filters on the front, top, bottom, and motherboard sides to protect the system.

Advanced Hardware Solutions

The AX700 TG Super Tower Chassis supports a 190mm CPU cooler, 630mm GPU (without HDD rack), and a 220mm power supply. It fits up to eighteen 120mm/140mm fans, a 560mm DIY or 420mm AIO radiator on top, and up to eighteen 3.5”/2.5” hard drives in the HDD cages and HDD trays. It can also be expanded by stacking with the AX100 for enhanced hardware solutions.

DMD: Dismantlable Modular Design

No more unreachable screw corners or gaps, installation can be a breeze with our Dismantlable Modular Design.

Specification

P/N : CA-11B-00F1WN-00

Series : AX Series

Model : AX700 TG

CASE TYPE : Super Tower

Dimension (H x W x D) : 645 x 324.6 x 685 mm (25.4 x 12.78 x 26.97 inch)

PANEL : Steel + TG

MATERIAL : SPCC

EXPANSION SLOTS : 10

I/O Port : USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 4, HD Audio x 1

PSU : Standard PS2 PSU (optional)

Drive Bays

2 x 5.25’’

12 x 3.5’’ or 2.5’’ (HDD Cage)

6 x 3.5’’ or 2.5’’ (Behind the M/B tray)

MOTHERBOARDS

6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) ,

12” x 13” (E-ATX) , 13.6” x 10.4” (XL-ATX) , SSI-CEB, SSI-EEB

FAN SUPPORT

Front: 3 x 120mm , 3 x 140mm

Top: 4 x 120mm , 4 x 140mm

Rear: 1 x 120mm , 1 x 140mm

Bottom: 2 x 120mm , 2 x 140mm

Right Side: 8 x 120mm , 8 x 140mm

RADIATOR SUPPORT

AIO-Radiator Support:

Front: 1 x 360mm (MAX), 1 x 420mm (MAX)

Top: 1 x 360mm (MAX), 1 x 420mm (MAX)

Rear: 1 x 120mm , 1 x 140mm

DIY- Radiator Support:

Front: 1 x 360mm (MAX), 1 x 420mm (MAX)

Top: 1 x 480mm (MAX), 1 x 560mm (MAX)

Rear: 1 x 120mm , 1 x 140mm

CLEARANCE

CPU cooler height limitation: 190mm

VGA length limitation:

360mm(with HDD rack)

630mm(without HDD rack)

PSU length limitation: 220mm (with two bottom fans)
