Arctic Liquid Freezer III Pro 360 A-RGB AIO Water Cooler (ACFRE00184A)

Integrated VRM Fan

PWM-controlled fan lowers the voltage regulator temperature, ensuring stable performance.

Offset Mounting for Intel and AMD

Shifts the cold plate to the CPU hotspot for more efficient heat transfer.

Intel Contact Frame

Optimized contact pressure distribution for longer CPU lifespan and improved heat dissipation.

Integrated Cable Management

Fan cables integrated into the sleeving simplify installation and minimize cable clutter.

The New P12 Pro Fans

More Performance at Any Speed

The P12 Pro unleashes its full potential: quieter and more powerful at low speeds, with greater performance reserves under load—for maximum cooling without compromise.

Premium-Class Radiator

The 38 mm radiator not only enhances heat dissipation but also holds more liquid than conventional 27 mm radiators. This reduces heat buildup and ensures more efficient handling of temperature spikes.

Premium Tubing

Reinforced EPDM tubing with braided sheathing for increased durability

Easy Installation

Pre-installed, pre-wired fans, straightforward mounting, and an animated online manual.

Includes MX-6 Thermal Paste

Simply apply in a cross pattern—the water pump’s cold plate distributes the paste evenly

Two Control Options

With the splitter cable, the pump, VRM fan, and radiator fans can be controlled separately or synchronized via a single PWM signal with the all-in-one cable.

Check Your Case for Compatibility

Please note that the Liquid Freezer requires at least 63 mm of clearance for installation

Limited Compatibility with Certain Motherboards

Some motherboards may be incompatible with the Liquid Freezer III Pro due to oversized SSD coolers in the M.2_1 slot. For affected motherboards, we provide a compatible M.2 cooler free of charge.

Specifications

Warranty: 6 Years

TIM : MX-6 (0.8 g)

Operating Ambient Temperature : 0—40 °C

PI | NNPI : 338 | 309

LED Connector : 3-Pin A-RGB Connector

All-In-One Connector : 4-Pin PWM Connector

Splitt Connector : 3x 4-Pin PWM Connector

Weight : 1870 g

Compatibillity

Intel : 1851, 1700

AMD : AM5, AM4

Pump Specifications

Pump : 800—2800 rpm (PWM controlled)

Current | Voltage : 0.35 A | 12 V DC

Cold Plate : Copper, Micro Skived Fins

Tube Length : 450 mm

Tube Diameter

Outer: 12.4 mm

Inner: 6.0 mm

Radiator Specifications

Material : Aluminium

Dimensions : 398 (L) x 120 (W) x 38 (H) mm

VRM Modul Specifications

VRM Fan : 400—2500 rpm (PWM controlled)

Current | Voltage : 0.05 A | 12 V DC

LEDs : 12x A-RGB LEDs

Current | Voltage : 0.40 A | 5 V DC

Fan Specifications

General : 3x P12 PWM PST A-RGB

Speed : 200—2000 rpm

Air Flow : 48.82 cfm | 82.91 m3/h

Static Pressure : 1.85 mmH2O

Bearing  : Fluid Dynamic Bearing

Current | Voltage : 0.11 A | 12 V DC

Cable Lenght : 40 mm

Connector : 4-Pin PWM Connector

RGB Specifications

LEDs : 12x A-RGB LEDs

Current | Voltage : 0.40 V | 5 V DC

Cable Lenght : 40 mm + 80 mm Splitter Cable

Connector : 3-Pin A-RGB Connector + 3-Pin Plug
