Corsair FRAME 4000D RS ARGB Modular Mid-Tower PC Case Black (CC-9011296-WW)

Key Features

• Fully-modular design for next-level customization
• InfiniRail™ Fan Mounting System for easier building
• Includes three RS120 ARGB performance fans
• Dual 360mm radiator support
• GPU anti-sag stabilization arm
• Compatible with reverse connector motherboards

50 SERIES GPUs ARE HERE

Pair a next-gen GPU with quality CORSAIR components for top-shelf performance and no hassles, right out of the box.

ENDLESS MODULAR POSSIBILITIES

The revolutionary FRAME Modular Case System redefines customization. Want to upgrade the motherboard tray to billet aluminum? Want to replace your front I/O panel for more USB ports? Now you can.

This case evolves with your needs, offering near limitless options for upgrades and changes.

INFINIRAIL FAN MOUNTING SYSTEM

This steel multi-point mounting system provides unmatched flexibility for front and roof fan configurations. Easily slide the rail to mount fans up to 200mm (140mm in the roof) exactly where you need them, ensuring targeted airflow without limitations of fixed mounting points.

DUAL 360mm RADIATOR SUPPORT

Boost your cooling with three dedicated mounting locations for 360mm radiators – front, roof, and side. You can mount up to 10x 120mm fans simultaneously, ensuring continuous cool air intake and efficient hot air exhaust.

THREE RS120 ARGB FANS INCLUDED

RS120 ARGB PWM daisy-chainable fans for simply great cooling - no separate controller needed.

Controlled through one 4-pin PWM connector and one +5V ARGB connector on your compatible motherboard.

GET IN THE FRAME

Ensure your build has excellent airflow with careful cable routing and support for the latest motherboards and graphics cards.

NO VISIBLE CABLES 

Fully compatible with reverse-connector motherboards from Asus, MSI, and Gigabyte, allowing for unobstructed airflow and a super-clean build.

SAG-FREE GRAPHICS CARDS

Every CORSAIR FRAME 4000D includes a GPU Anti-sag Stabilization Arm to keep your GPU steady, so you never have to worry about damaging your PCIe slot.

CABLE SHROUD

Keep unused and overly long cables out of sight with the cable shroud for a clean and organized interior.

WIDE COOLING FLEXIBILITY

Customize your cooling setup with room for up to 12x 120mm fans, plus versatile radiator mounting options including up to dual 360mm radiators.

MODERN FRONT PANEL I/O

Puts your connections within easy reach, including a USB 3.2 Gen 2 Type-C Port, 2x USB 3.2 Gen 1 Type-A ports, and a combination audio/microphone jack.

Specification

Case Height : 486

Case Length : 490

Case Width : 239

Material : Steel, Tempered Glass, 3D-Y Airflow Steel, Plastic

Motherboard Support : Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm)

Color : BLACK

Radiator Compatibility : 120mm, 140mm, 240mm, 280mm, 360mm

Maximum GPU Length : 430mm

Maximum CPU Cooler Height : 170mm

Maximum PSU Length : 220mm

Compatible Liquid Coolers : H60, H100, H115, H150, NAUTILUS, TITAN

Case Size : Mid-Tower

Case Power Supply : ATX

Case Expansion Slots : 7 Horizontal or 3 Vertical

Case Front IO : (1x) USB 3.2 Gen 2 Type-C, (2x) USB 3.2 Gen 1 Type-A, (1x) Audio in/out

Case Window : Tempered Glass

Internal 3.5" Drive Bays : 2

Internal 2.5" Drive Bays : 2

Radiator Support - Top : 360mm, 280mm, 240mm

Radiator Support - Front : 360mm, 280mm, 240mm

Radiator Support - Bottom : None

Radiator Support - Side : 360mm, 280mm, 240mm

Radiator Support - Rear : 140mm, 120mm

Fan Support - Top : 3x 120mm, 2x 140mm

Fan Support - Front : 3x 120mm, 2x 140mm, 2x 200mm

Fan Support - Bottom : 2x 120mm

Fan Support - Side : 3x 120mm, 2x 140mm

Fan Support - Rear : 1x 120mm, 1x 140mm

Front IO Motherboard Connections : 1x HD Audio; 1x USB 3.2 Gen1; 1x USB-3.2 Gen2 Type-E; 1x F_PANEL

Reverse Connector Motherboard Support : Yes

Included Fans : RS ARGB Series

Dust Filtration : Yes

Cable Routing Space : 37mm

RapidRoute Included : No

Left Side Panel : Tempered Glass

Right Side Panel : Steel

Vertical Mount Support : Supported (Riser Card Sold Separately)
