Gigabyte Radeon RX 6500 XT EAGLE 4G (GV-R65XTEAGLE-4GD)

FEATURES

Powered by AMD RDNA™ 2 Radeon™ RX 6500 XT

Integrated with 4GB GDDR6 64-bit memory interface

WINDFORCE 2X Cooling System with alternate spinning fans

Graphene nano lubricant

CORE CLOCK

Boost Clock* : up to 2815 MHz

Game Clock* : up to 2610 MHz

Intense 1080p Performance

AMD Radeon™ RX 6500 XT graphics cards deliver serious 1080p gaming and impressive frame rates. The power of AMD RDNA™ 2 architecture is unleashed with up to 16 powerful graphics compute units, coupled with all ultra-high bandwidth AMD Infinity Cache™, and up to 4GB of dedicated GDDR6 memory.

The Best Gaming Experience

For The Best Gaming Os

AMD Radeon™ graphics with Windows 11 enables the ultimate gaming experience through superior graphics, amazing performance, optimized security features. With support for DirectX® 12 Ultimate, Auto HDR, AMD Radeon graphics, and Radeon™ software all stand ready to supercharge your gaming experience with Windows 11.

  WINDFORCE 2X COOLING SYSTEM

The WINDFORCE 2X cooling system features two unique blade fans, alternate spinning, composite copper heat pipes, copper plate and 3D active fan, which together provide high efficiency heat dissipation

ALTERNATE SPINNING

Alternate Spinning can reduce the turbulence of adjacent fans and increase air pressure.

Specification                                                                                                                                                                                                                                                                 Graphics Processing : Radeon™ RX 6500 XT

Core Clock

Boost Clock* : up to 2815 MHz

Game Clock* : up to 2610 MHz

Stream Processors : 1024

Process Technology : 6 nm

Memory Clock : 18000 MHz

Memory Size : 4 GB

Memory Type : GDDR6

Memory Bus : 64 bit

Memory Bandwidth (GB/sec) : 144 GB/s

Card Bus : PCI-E 4.0

Digital max resolution : 7680x4320

Multi-view : 2

Card size : L=192 W=117 H=38 mm

PCB Form : ATX

DirectX : 12 Ultimate

OpenGL : 4.6

Recommended PSU : 400W

Power Connectors : 6 pin*1

Output : DisplayPort 1.4a *1HDMI 2.1 *1

Accessories : Quick guide
