NZXT Control Hub Digital RGB Lighting and Fan Speed Controller (AC-CRFR1-B1)

Overview

The NZXT Control Hub streamlines fan and RGB lighting management. Connect and customize your setup for optimal performance and vibrant visuals through NZXT CAM software.

Conveniently operate a full build of RGB Core Single-Frame Fans using the 8-pin PWM and RGB combo headers.

Fine-tune speeds for up to five PWM fans (including single-frame fan units), with Zero RPM mode for silent operation during low loads.

Synchronize lighting effects on up to five NZXT RGB components to create a cohesive, system-wide look.

Adjust fan speeds, personalize lighting, and create custom profiles via NZXT CAM software, which automatically detects each connected device.

Secure the controller magnetically or use the included 3M™ Dual Lock™ Reclosable Fasteners.

The included splitter cables have both 4-pin PWM and 4-pin RGB connectors, ensuring it works with any type of NZXT fan.

Specification

Dimensions

Height : 15.9 mm / 0.63 in

Width : 70 mm / 2.76 in

Depth : 100 mm / 3.94 in

Weight : 150 g / 5.29 oz

Output Channels

Fan : 3 x NZXT 8-pin (PWM only) / 1 x NZXT 8-pin (DC+PWM control) / 1 x 4-pin PWM (DC+PWM control)

RGB : 4 x NZXT 8-pin / 1 x NZXT RGB

Max LED Support : Each NZXT 8-pin channel supports up to 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to 5 NZXT devices.

Installation

Mounting Options : Magnetic housing, 3M™ Dual Lock™ Reclosable Fasteners, or 2.5" SSD mounting screws

PSU Connector : 8-pin PCIe Power

Motherboard Connector : Internal USB 2.0

System Requirements

Internal Header : USB 2.0

Operating System : Windows® 10/11

Software : NZXT CAM

General

Warranty : 2 Years
