Gamdias ATHENA M4M WOOD Micro Tower Case

NATURAL DESIGN. COMPACT POWER.

The ATHENA M4M WOOD is a compact micro-tower case that combines high performance with natural aesthetics. It features a fully perforated mesh front panel and a distinctive real wood I/O panel that adds a modern touch. The case comes with three 120mm NOTUS M1 fans to ensure optimized airflow while maintaining a clean look. With support for dual 360mm radiators, BTF motherboards, and GPUs up to 395mm, this case offers excellent thermal performance and broad hardware compatibility in a space-efficient design.

EXTENSIVE AIRFLOW CONFIGURATION

The ATHENA M4M WOOD allows robust airflow intake and exhaust configurations with a mesh front panel and perforated vents built throughout the case.

3 BUILT-IN NOTUS M1 FANS

The case comes with three 120mm NOTUS M1 fans, including two front intake fans and one rear exhaust fan, providing optimized airflow, efficient heat dissipation, and near-silent operation.

EASY ACCESS FRONT-MOUNTED PSU DESIGN

The PSU is strategically positioned at the front side of the case, with connector ports oriented downward for easier cable management. A PSU shroud enhances the clean aesthetic, and an extension cable is included to facilitate rear power connection

FLAWLESS VIEW

This case supports connector-hidden motherboard (BTF motherboard), enabling cables to plug in from the back for a cleaner front appearance and enhanced PC setups.

DUAL 360MM RADIATOR SUPPORT

The ATHENA M4M WOOD provides superior cooling performance as it can support 360mm radiators on the top and the bottom simultaneously.

SIMPLE AND ACCESSIBLE

The I/O features one USB 3.2 Gen 2 Type-C port for high transfer speeds up to 10 Gbps, two USB 3.0 port, a reset button, and additional audio connectivity.

SIMPLE CLASP MECHANISM

The case features a modular design that allows nearly every panel to be easily detached for better accessibility. The side panels are secured with a simple clasp mechanism, while the top panel is secured with thumb screws.

COOLING COMPATIBILITY

The ATHENA M4M WOOD can accommodate up to 9 fans and offers flexible options for the installation of radiators at the front, top, bottom and rear.

INTERIOR ACCOMMODATION

Designed with a compact form factor, the case offers the option to house up to m-ATX motherboards and VGA cards up to 395mm.

FLEXIBLE STORAGE SOLUTION

The interior configuration has ample room for cable management optimization and supports PSU lengths up to 150mm.

DUST RESISTANT

Equipped with dust filters on the top and side, the case effectively protects against dust while maintaining ventilation.

Secification

Case Type : Micro Tower

MB Support : Mini-ITX、Micro-ATX

Synchronization : 5V 3-Pin Addressable Header

CASE Color : Black

Expansion Slots : 5

Material : SPCC & ABS & Tempered glass & Wood

Window : Left

Radiator Support : Top: 360 mmFront: 240mmBottom: 360mm

Fan Support : Top: 3 x 120mmBottom: 3 x 120 mmFront : 2 x 120 mmRear: 1 x 120mm

Pre-installed Fans : Front: 2 x 120mm BK PWM FansRear: 1 x 120mm BK PWM Fan

Drive Bays : 1 x 3.5" + 1 x 2.5" or 2 x 2.5"

I/O Port : USB 3.0 x2, Type Cx1, HD Audio x1, Reset x1

Clearance : CPU cooler height limitation: 175mmVGA length limitation: 395mmPSU length limitation: 150mm

Dimension (L x W x H) : 446 x 235 x 347mm
