Asus ROG Strix GeForce RTX 5070 12GB GDDR7 OC Edition (STRIX-RTX5070-O12G)

ROG Strix GeForce RTX™ 5070 12GB GDDR7 OC Edition

Powered by the NVIDIA Blackwell architecture and DLSS 4

3.2-slot design: massive fin array optimized for airflow from the three Axial-tech fans

Axial-tech fans have been scaled up to propel 31% more air through the card to reach higher performance.

0dB technology lets you enjoy light gaming in relative silence

MaxContact design ensures efficient heat transfer, providing a premium performance

Phase-change GPU thermal pad helps ensure optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability.

Premium power delivery with digital power control and 15K caps ensure high performance.

Protective PCB Coating envelops the circuit board to help protect against short-circuits caused by moisture, dust or debris.

Aura Sync features Aura-compatible ARGB lighting on the shroud and perimeter allows endless personalization.

GPU Tweak III software provides intuitive performance tweaking, advanced thermal control and system monitoring

FIND YOUR EDGE

The premium performance ROG Strix GeForce RTX 5070, featuring advanced cooling system with axial-tech fan, phase-change GPU thermal pad and MaxContact design, lowering GPU temperature to reach higher performance. Aura sync provides endless possibilities for personalization with color or functional effects.

Fifth-Gen Tensor Cores

Max AI performance with FP4 and DLSS 4

New Streaming Multiprocessors

Optimized for neural shaders

Fourth-Gen Ray Tracing Cores

Built for Mega Geometry

Axial-tech Upgrades

Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel more air through the card, setting the stage for lower temperatures, less noise, and higher performance.

Reverse Rotation and 0dB Technology

The two side fans spin counterclockwise to reduce turbulence and improve airflow through the heatsink. All three fans stop when GPU temperatures are below 50°C, ensuring quiet operation during light tasks or less-demanding games. They resume operation above 55°C, following a speed curve that optimizes performance and noise levels.

Vented Backplate

Large backplate vents significantly enhance heat dissipation, helping to keep the GPU cooler during intense tasks. This additional airflow helps ensure optimal temperatures, boosting performance, longevity and stability by defending against overheating and thermal throttling.

A shorter PCB with optimized component and trace layouts reduces power loss and allows heat to escape through a large backplate vent.

Specifications

Graphic Engine : NVIDIA® GeForce RTX™ 5070

AI Performance : 1044 TOPs

Bus Standard : PCI Express 5.0

OpenGL : OpenGL®4.6

Video Memory : 12GB GDDR7

Engine Clock

OC mode: 2685MHz

Default mode: 2655MHz (Boost Clock)

CUDA Core : 6144

Memory Speed : 28 Gbps

Memory Interface : 192-bit

Resolution : Digital Max Resolution 7680 x 4320

Interface

Yes x 2 (Native HDMI 2.1b)

Yes x 3 (Native DisplayPort 2.1b)

HDCP Support Yes (2.3)

Maximum Display Support : 4

NVlink/ Crossfire Support : No

Accessories

1 x Speedsetup Manual

1 x ROG Graphics Card Holder

1 x ROG Velcro Hook & Loop

1 x ROG Magnet

1 x ROG PCB Ruler

1 x Thank You Card

1 x Adapter Cable (1 to 2)

Software

ASUS GPU Tweak III & MuseTree & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.

Dimensions

332 x 147.3 x 64 mm

13.07 x 5.79 x 2.519 inch

Recommended PSU : 750W

Power Connectors : 1 x 16-pin

Slot ; 3.2 Slot

AURA SYNC : ARGB
