Antec SF850X 850W 80 Plus Gold Small Form Factor PSU

Key Features

ATX 3.1 & PCIe 5.1 Compatible

Our new SF850X 80PLUS GOLD power supply is formally certified for ATX 3.1 compliance, meeting the high standards for reliability and power efficiency, and ensuring the utmost level of quality and performance. The included PCIe 5.1 12VHPWR GPU cable enables seamless compatibility with the latest graphics cards, such as the NVIDIA® GeForce RTX™ 40 Series.

High-Quality JP Capacitors

Equipped with high-quality JP capacitors, SF850X 80PLUS GOLD achieves unprecedented tight voltage regulation and minimal ripple and noise, maximizing your system's performance.

Compact Size

Compact yet powerful, SF850X 80PLUS GOLD is ideal for your ITX build with an intricated combination of quality, efficiency, and size.

Zero RPM Manager

The thermal sensors activate the fan only when necessary, providing optimal cooling while minimizing noise levels. With the Zero RPM fan mode, this PSU comes with a longer lifespan and quieter operations.

Full Modular Cable Management

Allowing users to use only the necessary cables and eliminates excess cables that can obstruct and reduce airflow, also provide a much cleaner look inside the PC case.

Specification

Model : SF850X 80PLUS Gold

Type : ATX 12V 3.1 (SFX 4.1)

Dimension : 100 x 125 x 63.5mm (LWH)

Modular : Full-Modular

Input Voltage : 100V-240V

Input Current : 12A-6A

Input Frequency Range : 60Hz-50Hz

PFC : Active PFC

Power Good Signal : 100-150ms

Protection : OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO

Output Capacity : 850W

Operation Temperature : 0~40°C

Regulatory :  cTUVus / TUV / CB / RCM / CE / FCC / BIS / BSMI / KC / UKCA / ICES / CCC

Fan : 92mm Silent Fan

Certifications : 80 Plus Gold

Unit Box Dimensions : 236 x 184 x 106mm (L*W*H)

Shipping Box Dimensions : 559 x 500 x 203mm (L*W*H)

Connector

1 x 24(20+4)pin MB

1 x 16(12+4)pin PCIE 5.1 12VHPWR

2 x 8(4+4)pin CPU

4 x 8(6+2)pin PCI-E

6 x SATA

2 x Molex
