TP Link 8-Port Gigabit Easy Smart Switch (TL-SG108E)

Key Features

8-Port Gigabit Easy Smart Switch

• 8 10/100/1000Mbps RJ45 ports
• Plug and play, with no configuration required
• Durable metal casing of superior quality and professional appearance
• Intelligent management via a web user interface and downloadable utility
• Green technology reduces power consumption

Link Your Devices, Create Convenient Business

The 8-Port Gigabit Easy Smart Desktop Switch provides an easy way to expand your wired network. Deal with your business quickly and easily, whether you are at home or in the office.

Gigabit Ports for Maximum Speed

8 non-blocking 10/100/1,000 Mbps ports make it possible to transfer large, bandwidth-intensive files with no interference.

QoS for a Lag-Free Experience

Ensures smooth traffic for latency sensitive applications, such as voice and video

IGMP Snooping for Multicast Optimization

Ensures a better network experience, especially for applications like IPTV, by optimizing multimedia traffic delivery.

VLAN for Security

Helps to create network with higher security and better overall performance by dividing network into smaller groups

Management Made Easy

TL-SG108E offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG108E offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.

Durable Metal Casing

The interior components of TL-SG108E are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG108E delivers switching performance you can depend on.

Go Green with Your Ethernet

TP-Link’s latest generation of Easy Smart Switches make use of innovative energy-saving technologies. Power consumption automatically adjusts according to link status and cable length, allowing you to expand your network while minimizing your carbon footprint. Save the planet and lower your energy bills — it’s a win-win!

Specification

HARDWARE

Standards and Protocols : IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p

Fan Quantity : Fanless

Power Supply : External Power Adapter(Output: 5 VDC/ 0.6 A)

Dimensions ( W x D x H ) : 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)

Max. Power Consumption : 3.68 W (220 V/ 50 Hz)

Max. Heat Dissipation : 12.55 BTU/h

Interface

8 10/100/1000 Mbps RJ45 Ports

AUTO Negotiation/AUTO MDI/MDIX

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

100BASE-TX: UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

PERFORMANCE

Switching Capacity  : 16 Gbps

Packet Forwarding Rate : 11.9 Mpps

MAC Address Table : 4 K

Packet Buffer Memory : 1.5 Mb

Jumbo Frame : 16 KB

SOFTWARE FEATURES

Transmission Method : Store-And-Forward

Quality of Service

Support Port-based/802.1p/DSCP priority

Support 4 priority queues

Rate Limit

Storm Control

L2 Features

IGMP Snooping V1/V2/V3

Static Link Aggregation

Port Mirroring

Cable Diagnostics

Loop Prevention

VLAN

Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)

MTU/Port/Tag VLAN

OTHERS

Certification : FCC, CE, RoHS

System Requirements : Microsoft® Windows® for running Utility

Package Content

TL-SG108E

Power Adapter

Installation Guide

Rubber Feet

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
